Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE

Shenzhen Createk Technology Co., Ltd
Contact Now
    Buy cheap Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE from wholesalers

    Buy cheap Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE from wholesalers
    • Buy cheap Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE from wholesalers
    • Buy cheap Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE from wholesalers
    • Buy cheap Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE from wholesalers
    • Buy cheap Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE from wholesalers
    • Buy cheap Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE from wholesalers

    Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE

    Ask Lasest Price
    Brand Name : Createk
    Model Number : ITBG601-P
    Certification : CE, RoHS, FCC, KC
    Price : USD36 / negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100k pcs/ month
    Delivery Time : 3 weeks
    • Product Details
    • Company Profile

    Smart DC28V 100 Meters Bluetooth WIFI Gateway Triangle Localization POE

    Bluetooth gateway 4.2/5.0 big range 100m compatible different devices and protocols filtering tri-angle localization POE


    Model Number: ITBG601-P

    Bluetooth gateway indoor type ITBG601-P_BLE 4.2, Ethernet


    Product Overview:


    ITBG601 is a Bluetooth gateway that supports Bluetooth 4.2. The ITBG601 Bluetooth gateway integrates PA and LNA, and the Bluetooth scanning and connection distance can reach more than 100 meters, which greatly increases the coverage area and reduces the user cost. ITBG601 can support POE power supply (in accordance with IEEE 802.3at (Class 1) requirements) or power adapter power supply (wide voltage range: 6V-24V). ITBG601 can be compatible with different Bluetooth terminal devices, which is convenient for users to collect and remotely control the data of Bluetooth terminal devices (such as Bluetooth bracelets, Bluetooth skipping ropes, Bluetooth door locks, various Bluetooth sensors, etc.) through the connection with Bluetooth terminal devices. Two-way transmission of data. ITBG601 and background communication methods support: UDP, TCP. Supports Bluetooth filtering methods including Bluetooth name filtering, signal strength filtering, MAC address filtering, etc. ITBG601 supports remote software upgrade function. The signal strength (RSSI value) of the Bluetooth signal of the Bluetooth terminal is received by the Bluetooth gateway, and the distance from the Bluetooth terminal to multiple Bluetooth gateways can be calculated, and then triangulation can be realized. ITBG601 is widely used in medical, elderly care, sports, sports, fitness, education, home, and various industrial applications.


    Product Characteristic


    Support PoE power supply or power adapter power supply;

    Support Bluetooth ® 4.2;

    Integrated Bluetooth PA/LNA;

    An Ethernet port;

    Comply with RoHS standard;

    Comply with FCC and CE standards


    Product Specification


    Product sizeDiameter:124mm; Height:40mm
    Power

    DC6-28V(2A)

    PoE (PoE switch up to 57V), IEEE 802.3at(Class1) compliant

    Working current

    280mA@12V (with 4G module)

    180mA@12V (without 4G module)

    Operating temperature-20℃~70℃
    InterfaceEthernet port, power interface, reset button
    WiFi
    WiFi protocolIEEE 802.11n, IEEE 802.11g, IEEE 802.11b
    Data rateIEEE 802.11 b Standard Mode: 1,2,5.5,11Mbps
    IEEE 802.11 g Standard Mode: 6,9,12,18,24,36,48,54Mbps

    IEEE 802.11n : 72Mbps @ HT20

    150Mbps @ HT40

    Receive sensitivityHT40 MCS7 : -67dBm@10% PER(MCS7)
    HT20 MCS7 : -73dBm@10% PER(MCS7)
    54M: -76dBm@10% PER
    11M: -91dBm@ 8% PER
    Transmit power

    IEEE 802.11n: 15dBm @HT40 MCS7

    15dBm@HT20 MCS7

    IEEE 802.11g: 16dBm
    IEEE 802.11b: 18dBm
    Wireless securityWPA/WPA2, WEP, TKIP, and AES
    Working modeBridge,Gateway,AP Client
    Bluetooth
    Bluetooth protocolBluetooth ® 5.0
    The data rateUncoded: 1Mbps/2Mbps
    Wireless securityAES HW Encryption
    The connection distance

    100m


    Transmit power0~+18dBm
    4G LTE
    Communication protocol

    LTE-TDD/LTE-FDD/TD-SCDMA/UMTS/

    EVDO/EDGE/GPRS/GSM/CDMA


    R&Q:


    • Does the Bluetooth gateway need a network?

    The Bluetooth gateway is an integrated Bluetooth and wifi module device, which can connect to the network via 4G/WiFi/Ethernet for data transmission. Createk Bluetooth gateway can be with or without 4G according to the customer's choice. If the wireless layout needs to connect to WiFi, it is powered by the power adapter at this time; if it is connected to the Ethernet wired network, it can be powered by POE. For more details about the Bluetooth gateway, please contact with us


    • How does the bluetooth beacon realize the indoor positioning and promotion of shopping malls?

    First, the Bluetooth beacon needs to be placed in the application location (such as a shopping mall). Secondly, the user needs to use a small program or APP that loads the Bluetooth beacon related function code + indoor map + algorithm, etc. and turn on the Bluetooth. Finally, when the user enters the Bluetooth After the broadcast range of the beacon, according to the location information of the 3 strongest Bluetooth beacons, the mobile phone program calculates the current location and displays it on the map. Enter the destination and you can navigate to the place you want to go.
